Description
10 ΧΡΟΝΙΑ ΕΓΓΥΗΣΗ
Χαρακτηριστικά:
Για εγκαταστάσεις στον τοίχο ή γυψοσανίδες
Χαλύβδινο πλαίσιο με επικάλυψη, αυτοστηριζόμενο
Για στεγνή επένδυση, πλήρως προσυναρμολογημένη
Με σταθερές συνδέσεις
Δύο μπουλόνια στερέωσης λεκάνης
Απόσταση μπουλονιών τοποθέτησης 180/230 χιλ
Outlet bend Ø 90 mm
Depth adjustable
Reducer Ø 90/110 mm
Σετ σύνδεσης εισόδου και εξόδου
Flushing cistern SLIM, 3 – 6 l, containing following features:
Adjustment ex factory 6 l and 3 l
Pneumatic discharge valve offering 3 modes of operation: dual flush or start/stop or single flush
Water supply from top
Mονωμένο κατά της συμπύκνωσης
1/2″ water supply connection including integrated angle valve and push fit flexible hose union
Shortable inspection shaft incl. protection during construction phase, for vertical use
For on-the-wall installation wall brackets 39 699 000 need to be ordered separately
For mounting of small flush plates revision shaft 40 949 000 to be ordered separately
